Branch Prediction and Speculative Execution: How Modern CPUs Gamble on the Future
Explore how modern processors predict branch outcomes and execute instructions speculatively, the algorithms behind branch predictors, the performance implications for your code, and the security vulnerabilities like Spectre that emerged from these optimizations.
Modern CPUs are marvels of prediction. Every time your code branches—every if statement, every loop iteration, every function call—the processor makes a bet on what happens next. Get it right, and execution flows at full speed. Get it wrong, and the pipeline stalls while work is thrown away. Understanding branch prediction transforms how you think about code performance. This post explores the algorithms, trade-offs, and real-world implications of one of computing’s most important optimizations.
1. Why Prediction Matters
Consider a simple loop:
for (int i = 0; i < 1000000; i++) {
sum += array[i];
}
At the machine level, this becomes a branch instruction that checks i < 1000000. A modern CPU might take 15-20 cycles to determine the branch outcome (waiting for the comparison to complete). With a 3 GHz processor, that’s 5-7 nanoseconds per iteration—just for the branch.
But the processor doesn’t wait. It predicts the branch will be taken (loop continues) and keeps fetching instructions. One million correct predictions mean the branch overhead is nearly eliminated. The final iteration mispredicts (loop exits), costing ~15 cycles—a trivial price for eliminating millions of stalls.
1.1 The Pipeline Problem
Modern CPUs use deep pipelines to maximize throughput:
Instruction Pipeline (simplified):
┌──────┬──────┬──────┬──────┬──────┬──────┬──────┐
│Fetch │Decode│Rename│Issue │Execute│Memory│Retire│
└──────┴──────┴──────┴──────┴──────┴──────┴──────┘
│ │ │ │ │ │ │
Cycle 1 2 3 4 5 6 7
While instruction N is executing, the CPU is already fetching N+1, N+2, N+3, and so on. But what if N is a branch? The CPU doesn’t know which instructions come next until the branch resolves.
Without prediction: Stop fetching until the branch resolves. The pipeline drains, wasting cycles equal to the pipeline depth (15-20+ stages on modern CPUs).
With prediction: Guess the branch outcome, keep fetching instructions from the predicted path. If correct, no cycles lost. If wrong, flush the speculative work and restart.
1.2 The Cost of Misprediction
When a branch mispredicts:
- All speculatively executed instructions are discarded
- The pipeline is flushed
- Fetch restarts from the correct path
- The pipeline must refill before useful work resumes
Misprediction penalty: 10-25 cycles on modern CPUs, depending on how deep the speculation went.
A branch that mispredicts 10% of the time with a 20-cycle penalty:
- Average cost: 0.10 × 20 = 2 cycles per branch
- For a tight loop with one branch per iteration, this is significant!
2. Static Branch Prediction
Early processors used simple, static rules.
2.1 Backward Taken, Forward Not Taken (BTFNT)
The simplest heuristic:
- Backward branches (target address < current address): Predict taken. These are usually loops.
- Forward branches (target address > current address): Predict not taken. These are usually early exits.
// Backward branch - usually loops, predict taken
loop:
...
jnz loop // Predict: taken
// Forward branch - usually ifs, predict not taken
test eax, eax
jz skip // Predict: not taken
...
skip:
BTFNT achieves ~65% accuracy on typical code—better than random, but far from ideal.
2.2 Compiler Hints
Some ISAs allow the compiler to provide hints:
// GCC built-in for branch hints
if (__builtin_expect(error_condition, 0)) {
// Unlikely path
handle_error();
}
// Linux kernel macros
if (likely(condition)) { ... }
if (unlikely(condition)) { ... }
These hints can influence:
- Static prediction (on CPUs that use hints)
- Code layout (likely path falls through, unlikely path jumps)
- Instruction scheduling around the branch
2.3 Limitations of Static Prediction
Static prediction can’t adapt to:
- Runtime data patterns
- Phase behavior (different behavior at different times)
- Input-dependent branches
Modern CPUs use dynamic prediction that learns from runtime behavior.
3. Dynamic Branch Prediction
Dynamic predictors observe branch behavior and learn patterns.
3.1 One-Bit Predictor
The simplest dynamic predictor: remember the last outcome.
State: Last outcome (Taken or Not Taken)
Prediction: Same as last outcome
Branch history: T T T T T T T N T T T T
Predictions: ? T T T T T T T N T T T
Correct: - ✓ ✓ ✓ ✓ ✓ ✓ ✗ ✗ ✓ ✓ ✓
Problem: A loop that executes N times will mispredict twice per invocation:
- First iteration: May mispredict if loop wasn’t taken last time
- Last iteration: Always mispredicts (predicts taken, but loop exits)
For a loop executed millions of times, two mispredictions per invocation is fine. For a loop executed 5 times inside an outer loop of millions, that’s 2 million mispredictions!
3.2 Two-Bit Saturating Counter
Add hysteresis: don’t change prediction on a single wrong outcome.
States:
00: Strongly Not Taken (predict NT)
01: Weakly Not Taken (predict NT)
10: Weakly Taken (predict T)
11: Strongly Taken (predict T)
Transitions:
On Taken outcome: Increment (max 11)
On Not Taken outcome: Decrement (min 00)
State diagram:
Taken Taken
┌──────────┐ ┌──────────┐
▼ │ ▼ │
┌────────┐ ┌────────┐ ┌────────┐ ┌────────┐
│ 00 │──│ 01 │──│ 10 │──│ 11 │
│Strong NT│ │Weak NT │ │Weak T │ │Strong T│
└────────┘ └────────┘ └────────┘ └────────┘
│ ▲ │ ▲
└──────────┘ └──────────┘
Not Taken Not Taken
Benefit: A single anomaly doesn’t flip the prediction. The inner loop problem is greatly reduced:
- Loop entry: May be weak, but strong after first execution
- Loop exit: Mispredicts, but stays “weakly taken” for next invocation
- Next invocation: Correctly predicts taken on first iteration!
3.3 Branch Target Buffer (BTB)
Prediction isn’t just about direction (taken/not taken). For taken branches, we need the target address.
Branch Target Buffer: A cache mapping branch addresses to target addresses.
┌─────────────────┬────────────────────┬──────────────┐
│ Branch PC Tag │ Target Address │ Prediction │
├─────────────────┼────────────────────┼──────────────┤
│ 0x4000_1234 │ 0x4000_5678 │ 11 (Strong T)│
│ 0x4000_2000 │ 0x4000_2100 │ 01 (Weak NT) │
│ ... │ ... │ ... │
└─────────────────┴────────────────────┴──────────────┘
When a branch is fetched:
- Look up branch PC in BTB
- If hit: Use stored target and prediction
- If miss: Use static prediction, compute target when branch executes
BTB entries are limited, so not all branches can be tracked. Working set size matters!
4. Correlating Predictors
Some branches correlate with other branches or with global execution history.
4.1 Local History
A branch may have a pattern based on its own history:
for (int i = 0; i < n; i++) {
if (i % 2 == 0) {
even_work();
}
}
This branch alternates: T, N, T, N, T, N…
A local history predictor tracks recent outcomes for each branch:
Local History Table:
┌─────────────────┬────────────────┬──────────────┐
│ Branch PC │ History (4b) │ Prediction │
├─────────────────┼────────────────┼──────────────┤
│ 0x4000_1234 │ 1010 │ Pattern: alt│
│ 0x4000_2000 │ 1111 │ Pattern: T │
└─────────────────┴────────────────┴──────────────┘
The history bits index into a Pattern History Table (PHT) of 2-bit counters:
Pattern History Table for branch 0x4000_1234:
History │ Counter │ Prediction
────────┼─────────┼───────────
0000 │ 01 │ NT
0001 │ 11 │ T
0010 │ 10 │ T
... │ ... │ ...
1010 │ 01 │ NT ← Current history predicts NT
This captures repeating patterns within a single branch.
4.2 Global History
Branches often correlate with each other:
if (x < 0) {
// ...
}
// Later:
if (x < 0) { // Same condition - perfectly correlated!
// ...
}
Or more subtly:
if (ptr != NULL) {
if (ptr->valid) { // Very likely taken if first branch was taken
// ...
}
}
Global History Register (GHR): A shift register tracking the outcomes of recent branches (not just this branch).
GHR after sequence T, N, T, T, N, T:
┌───┬───┬───┬───┬───┬───┐
│ T │ N │ T │ T │ N │ T │
└───┴───┴───┴───┴───┴───┘
↑
Most recent
The GHR indexes into a global Pattern History Table:
Prediction for current branch = PHT[hash(BranchPC, GHR)]
4.3 gshare Predictor
The gshare predictor XORs the branch PC with the GHR to index the PHT:
Branch PC
│
▼
┌─────────┐
│ XOR │◄──── Global History Register
└────┬────┘
│
▼
┌─────────────────────┐
│ Pattern History │
│ Table (2-bit │
│ counters) │
└─────────────────────┘
│
▼
Prediction
gshare captures both:
- Branch-specific patterns (from PC bits)
- Global correlation (from GHR bits)
It’s simple, effective, and widely used as a baseline.
4.4 Tournament Predictors
Different predictors excel at different branch types. A tournament predictor uses multiple predictors and learns which is best for each branch:
┌──────────────┐
┌─────────│ Local Pred. │─────────┐
│ └──────────────┘ │
│ │
│ ┌──────────────┐ ▼
Branch ──┼────────│ Global Pred. │────────►MUX ──► Prediction
│ └──────────────┘ ▲
│ │
│ ┌──────────────┐ │
└─────────│ Chooser │─────────┘
└──────────────┘
The chooser table tracks which predictor was more accurate for each branch (or branch pattern). Alpha 21264 used this design, achieving ~95% accuracy.
5. Modern Branch Predictors
Contemporary CPUs use highly sophisticated predictors with multiple levels.
5.1 TAGE: Tagged Geometric History Length
TAGE (TAgged GEometric) is the dominant predictor design in modern CPUs.
Key insight: Different branches need different history lengths. Loop counters need short history. Complex control flow needs long history.
TAGE uses multiple tables with geometrically increasing history lengths:
Tagged Tables
┌──────┬──────┬──────┬──────┐
│ T1 │ T2 │ T3 │ T4 │
│ 4-bit│ 8-bit│16-bit│64-bit│
│ hist │ hist │ hist │ hist │
└──────┴──────┴──────┴──────┘
│ │ │ │
▼ ▼ ▼ ▼
┌───────────────────────────┐
│ Provider Select │
│ (longest match wins) │
└───────────────────────────┘
│
▼
Prediction
Each table entry has:
- Tag (partial PC + history hash)
- Prediction counter (2-3 bits)
- Useful counter (for replacement)
The table with the longest matching history provides the prediction. TAGE achieves ~97% accuracy on typical workloads.
5.2 Perceptron Predictors
Neural-inspired predictors learn weights for history bits:
Prediction = sign(w₀ + Σ(wᵢ × hᵢ))
Where:
w₀ = bias weight
wᵢ = weight for history bit i
hᵢ = history bit i (+1 for taken, -1 for not taken)
Training is simple: if mispredicted, adjust weights toward the correct outcome.
Perceptrons can capture complex correlations that table-based predictors miss. AMD’s Zen architecture uses perceptron-based predictors.
5.3 Loop Predictors
Loops have predictable iteration counts. Dedicated loop predictors detect and track loops:
Loop Predictor Entry:
┌─────────────┬───────────┬───────────┬──────────┐
│ Branch PC │ Limit │ Count │ Confident│
├─────────────┼───────────┼───────────┼──────────┤
│ 0x4000_1234 │ 100 │ 57 │ Yes │
└─────────────┴───────────┴───────────┴──────────┘
Prediction: Taken until Count reaches Limit
When a loop is detected (repeated back-edge), the predictor:
- Learns the iteration count
- Predicts taken until count reached
- Predicts not taken on final iteration
This eliminates the “last iteration” misprediction that plagues other predictors.
5.4 Return Address Stack
Function returns are indirect branches (target varies). But they follow a pattern: return to the instruction after the call.
Return Address Stack (RAS): A small stack that tracks call sites.
Call site 0x1000 ──► Push 0x1004
Call site 0x2000 ──► Push 0x2004
Call site 0x3000 ──► Push 0x3004
Return ──► Pop 0x3004 (predict return to 0x3004)
Return ──► Pop 0x2004 (predict return to 0x2004)
Return ──► Pop 0x1000 (predict return to 0x1004)
RAS handles returns with near-perfect accuracy for normal call/return patterns. Problems arise with:
- Exceptions (unwind stack without returns)
- Tail calls (return address isn’t pushed)
- Speculation (speculative calls corrupt RAS)
Modern CPUs use techniques like checkpointing to recover RAS on misprediction.
6. Indirect Branch Prediction
Most branches have a fixed target (direct branches). But some have variable targets:
// Virtual function call
obj->method(); // Target depends on object's vtable
// Switch statement (jump table)
switch (x) { ... } // Target depends on x
// Function pointer
callback(data); // Target is the function pointer value
6.1 Indirect Target Array (ITA)
Simple approach: cache recently seen targets.
┌─────────────────┬────────────────────┐
│ Branch PC │ Recent Targets │
├─────────────────┼────────────────────┤
│ 0x4000_1234 │ 0x5000, 0x6000 │
│ 0x4000_2000 │ 0x7000 │
└─────────────────┴────────────────────┘
Predict the most recently seen target. Works well for monomorphic call sites (one target) but poorly for polymorphic calls.
6.2 Indirect Target Predictor with History
Like branch direction, indirect targets can correlate with history:
switch (state) {
case A: next_state = B; break;
case B: next_state = C; break;
case C: next_state = A; break;
}
// Repeating pattern: A→B→C→A→B→C...
Modern indirect predictors use history to predict targets:
Prediction = TargetTable[hash(BranchPC, GHR)]
6.3 Virtual Call Optimization
Virtual calls are common in OOP code. Techniques to help prediction:
Devirtualization: Compiler converts virtual calls to direct calls when the type is known.
Polymorphic inline caches: At runtime, cache recent receiver types and inline the predicted path.
// Polymorphic inline cache (pseudocode)
if (obj->type == cached_type) {
cached_method(obj); // Fast path, direct call
} else {
obj->vtable[method_index](obj); // Slow path
cached_type = obj->type; // Update cache
}
7. Speculative Execution
Branch prediction enables speculation—executing instructions before knowing if they should execute.
7.1 How Speculation Works
Time ──────────────────────────────────────────────►
Instruction stream: A, B, BRANCH, C, D, E...
Pipeline:
Cycle 1: Fetch A
Cycle 2: Fetch B, Decode A
Cycle 3: Fetch BRANCH, Decode B, Execute A
Cycle 4: Fetch C (speculative!), Decode BRANCH, Execute B
Cycle 5: Fetch D (speculative!), Decode C, Execute BRANCH
└─► Branch resolves: prediction was CORRECT
Cycle 6: Fetch E, Decode D, Execute C (all valid!)
If prediction was WRONG:
Cycle 5: Branch resolves wrong
Flush C, D from pipeline
Restart fetch from correct path
7.2 Speculative State Management
Speculative instructions can’t modify permanent state until the branch is confirmed. CPUs use:
Reorder Buffer (ROB): Instructions complete out-of-order but retire (commit) in order. Speculative instructions wait in the ROB until the branch commits.
Physical Register File: Results are written to physical registers. Architectural registers are updated only on retirement.
Store Buffer: Stores wait in a buffer until retirement, then write to cache.
7.3 Memory Ordering and Speculation
Speculative loads are tricky:
if (x < array_size) { // Mispredicted as taken
value = array[x]; // Speculative load (x might be out of bounds!)
}
The load executes speculatively, potentially accessing invalid memory. Modern CPUs:
- Allow speculative loads (for performance)
- Check bounds when the load retires
- Squash if the load was invalid
But the load still affects microarchitectural state (caches, TLBs), leading to security issues…
8. Security: Spectre and Friends
Speculative execution vulnerabilities shocked the industry in 2018. They exploit the side effects of mispredicted speculation.
8.1 Spectre Variant 1: Bounds Check Bypass
if (x < array1_size) { // Can be mispredicted!
y = array2[array1[x] * 256]; // Speculatively executed with bad x
}
Attack:
- Train predictor to expect branch taken
- Call with
xout of bounds - Speculative execution reads
array1[x](secret data) - Uses secret as index into
array2, loading a cache line - Branch misprediction detected, execution rolled back
- But: Cache state persists! The loaded cache line reveals the secret
This leaks arbitrary memory through cache timing side channels.
8.2 Spectre Variant 2: Branch Target Injection
Indirect branch prediction can be poisoned:
- Attacker trains BTB with malicious target
- Victim process executes indirect branch
- Speculation jumps to attacker-chosen “gadget”
- Gadget leaks secrets via cache side channel
- Speculation rolled back, but cache side effects remain
This allows cross-process and cross-privilege attacks.
8.3 Mitigations
Software mitigations:
// Speculation barrier
if (x < array_size) {
__asm__ volatile("lfence"); // Block speculation
y = array[x];
}
// Array index masking
x &= ~(-(x >= array_size)); // Clamp x to valid range
Hardware mitigations:
- IBRS/IBPB: Indirect Branch Restricted/Prediction Barrier
- STIBP: Single Thread Indirect Branch Predictor
- Enhanced IBRS: Hardware mode that isolates prediction
- Microcode updates: Various fixes for specific variants
Performance impact: Mitigations can cost 2-30% performance depending on workload and mitigation level.
8.4 The Fundamental Problem
Speculation side channels exist because:
- Prediction affects what instructions execute (even speculatively)
- Speculative execution affects microarchitectural state
- Microarchitectural state is observable through timing
Fixing this fundamentally would require either:
- Never speculate (massive performance loss)
- Isolate all microarchitectural state (extremely difficult)
- Eliminate timing side channels (practically impossible)
Modern CPUs continue to balance security and performance with targeted mitigations.
9. Writing Branch-Prediction-Friendly Code
Understanding prediction helps you write faster code.
9.1 Make Branches Predictable
Sort data when possible:
// Unpredictable: random true/false
for (int i = 0; i < n; i++) {
if (data[i] >= 128) { // ~50% taken if random
sum += data[i];
}
}
// Better: sort first, then all false followed by all true
std::sort(data, data + n);
for (int i = 0; i < n; i++) {
if (data[i] >= 128) { // First N iterations false, rest true
sum += data[i];
}
}
The sorted version can be 3-5x faster due to better prediction!
9.2 Use Conditional Moves
Replace branches with conditional moves when possible:
// Branchy version
if (a > b) {
max = a;
} else {
max = b;
}
// Branchless version (compiler may generate CMOV)
max = (a > b) ? a : b;
// Explicitly branchless
max = b ^ ((a ^ b) & -(a > b));
Conditional moves have fixed latency (~1-2 cycles) regardless of data patterns. Useful when:
- Branch is unpredictable (near 50/50)
- Both paths are simple (cheap to compute both)
Warning: Don’t use branchless code blindly! If the branch is predictable, branches are faster because they can speculate ahead.
9.3 Loop Unrolling
Reduce branch overhead by processing multiple elements per iteration:
// Original: 1 branch per element
for (int i = 0; i < n; i++) {
sum += a[i];
}
// Unrolled: 1 branch per 4 elements
for (int i = 0; i < n; i += 4) {
sum += a[i] + a[i+1] + a[i+2] + a[i+3];
}
Fewer branches = fewer opportunities for misprediction.
9.4 Profile-Guided Optimization (PGO)
Let the compiler learn branch behavior:
# Step 1: Build instrumented binary
gcc -fprofile-generate -O2 program.c -o program
# Step 2: Run with representative workload
./program typical_input.txt
# Step 3: Rebuild with profile data
gcc -fprofile-use -O2 program.c -o program
PGO enables:
- Better branch prediction hints
- Hot path optimization
- Cold path outlining
- Better inlining decisions
PGO can improve performance by 10-30% for branch-heavy code.
9.5 Avoid Unpredictable Indirect Branches
Virtual calls and function pointers are indirect branches:
// Hard to predict: polymorphic
for (Shape* s : shapes) {
s->draw(); // Different target each time
}
// Easier to predict: monomorphic or sorted
std::sort(shapes.begin(), shapes.end(),
[](auto a, auto b) { return typeid(*a).name() < typeid(*b).name(); });
for (Shape* s : shapes) {
s->draw(); // Targets cluster together
}
10. Measuring Branch Performance
10.1 Performance Counters
Modern CPUs provide hardware counters for branch events:
# Linux perf
perf stat -e branches,branch-misses ./program
# Example output:
# 1,234,567,890 branches
# 12,345,678 branch-misses # 1.00% of all branches
Key metrics:
- Branch misprediction rate: Aim for < 2% on hot paths
- Instructions per branch: Lower means more control flow
- Branch MPKI: Mispredictions per kilo-instructions
10.2 Microbenchmarking
Isolate branch prediction effects:
// Predictable pattern
for (int i = 0; i < N; i++) {
if (i % 2 == 0) sum++; // Alternating: TNTNTN...
}
// Unpredictable pattern
for (int i = 0; i < N; i++) {
if (rand() % 2 == 0) sum++; // Random: ???
}
Compare performance to quantify prediction impact.
10.3 CPU-Specific Analysis
Intel VTune and AMD uProf provide detailed branch analysis:
- Per-branch misprediction rates
- BTB hit/miss rates
- Indirect branch target patterns
- Speculation efficiency
11. Branch Prediction Across Architectures
11.1 x86 (Intel/AMD)
Intel Haswell and later use TAGE-like predictors with:
- Multiple prediction tables
- Loop predictors
- Return address stack (16-32 entries)
- Indirect target predictors
AMD Zen uses perceptron-based predictors with:
- TAGE backup
- Large history lengths
- Sophisticated indirect prediction
Both achieve ~97% accuracy on typical workloads.
11.2 ARM
ARM cores vary widely:
- Cortex-A55 (efficiency): Simple bimodal predictor, ~85% accuracy
- Cortex-A78 (performance): TAGE-like, ~95% accuracy
- Apple M-series: Highly sophisticated, possibly perceptron-based
ARM’s big.LITTLE design means prediction quality varies between cores.
11.3 RISC-V
RISC-V is an ISA, not an implementation. Predictors vary by vendor:
- SiFive U74: gshare-based, moderate accuracy
- Alibaba XuanTie: TAGE-based, high accuracy
- Research implementations: Testing novel predictor designs
11.4 GPU “Prediction”
GPUs handle branches differently:
SIMD Execution:
Thread 0: if (true) { A } else { B }
Thread 1: if (true) { A } else { B }
Thread 2: if (false) { A } else { B }
Thread 3: if (true) { A } else { B }
Execution:
1. All threads execute A (thread 2 masked)
2. All threads execute B (threads 0,1,3 masked)
GPUs don’t predict; they execute both paths with masking. This is called divergence and is why GPU code should minimize branches.
12. Advanced Topics
12.1 Branch Prediction and SMT
Simultaneous Multithreading (Hyper-Threading) shares prediction resources:
- BTB entries are shared or partitioned
- GHR may be per-thread or shared
- Prediction tables compete for space
Competing threads can cause prediction interference. Some CPUs partition resources for security (prevent cross-thread Spectre attacks).
12.2 Speculative Memory Disambiguation
Modern CPUs speculate on memory dependencies:
store [A], value1
load [B] // Does B alias A?
// CPU speculates "no alias", executes load early
// If wrong, replay the load after the store completes
This is called memory disambiguation prediction. Misprediction causes pipeline flushes similar to branch misprediction.
12.3 Value Prediction
Why stop at predicting branches? We could predict values:
x = load_from_memory(); // Predict x = 42
y = x + 1; // Speculatively compute y = 43
Value prediction has been researched for decades but isn’t in mainstream CPUs due to:
- Complexity of recovery on misprediction
- Limited accuracy for most values
- Area/power costs
Some specialized uses exist (stride predictors for addresses).
12.4 Machine Learning Predictors
Research explores ML for prediction:
- Neural networks for branch prediction
- Reinforcement learning for predictor training
- Learned index structures for BTB
Challenge: ML inference must complete in < 1 cycle, limiting model complexity.
13. Historical Perspective
13.1 Early Predictors (1980s)
- Simple static prediction
- One-bit dynamic predictors
- Small BTBs
Accuracy: ~70-80%
13.2 Two-Level Predictors (1990s)
- Local and global history
- gshare, gselect
- Tournament predictors
Accuracy: ~90-95%
13.3 Modern Predictors (2000s-present)
- TAGE and variants
- Perceptron predictors
- Sophisticated loop/return prediction
Accuracy: ~97%+
- Sophisticated loop/return prediction
Accuracy: ~97%+
13.4 The Accuracy Wall
Prediction accuracy has plateaued:
- Easy branches are already perfect
- Hard branches are fundamentally unpredictable
- Diminishing returns from predictor complexity
Future gains likely come from:
- Reducing misprediction penalty
- Better speculative execution management
- Compiler assistance
14. Real-World Case Studies
Understanding branch prediction theory is valuable, but seeing real performance impacts cements the knowledge.
14.1 The Sorted Array Benchmark
The famous Stack Overflow question “Why is processing a sorted array faster than an unsorted array?” demonstrates branch prediction perfectly:
int main() {
const int arraySize = 32768;
int data[arraySize];
// Fill with random values 0-255
for (int c = 0; c < arraySize; ++c)
data[c] = std::rand() % 256;
// Optionally sort
// std::sort(data, data + arraySize);
long long sum = 0;
for (int i = 0; i < 100000; ++i) {
for (int c = 0; c < arraySize; ++c) {
if (data[c] >= 128)
sum += data[c];
}
}
}
Results:
- Unsorted: ~10 seconds
- Sorted: ~2 seconds
The sorted version is 5x faster because the branch becomes predictable. First half: all not-taken. Second half: all taken.
14.2 JSON Parsing Branches
JSON parsers are branch-heavy, checking character types continuously:
while (*p) {
if (*p == '"') parse_string();
else if (*p == '{') parse_object();
else if (*p == '[') parse_array();
else if (isdigit(*p)) parse_number();
// ...
}
Optimized parsers like simdjson use:
- SIMD to classify multiple characters at once
- Branchless state machines
- Data-parallel parsing
simdjson achieves 2-4GB/s versus ~200MB/s for traditional parsers, largely by eliminating unpredictable branches.
14.3 Game Engine Physics
Physics engines often process many objects:
for (Entity& e : entities) {
if (e.hasPhysics) {
if (e.isAwake) {
if (e.collisionEnabled) {
// Process physics
}
}
}
}
Optimizations:
- Sort entities by type (all physics entities together)
- Use data-d8a620d design (separate arrays for different properties)
- Process in batches of similar entities
Modern engines achieve 10-100x improvements through branch-friendly data organization.
14.4 Database Query Processing
Database queries involve many branches:
// Filter predicate
for (Row& row : table) {
if (row.age > 30 && row.salary > 50000 && row.dept == "ENG") {
results.push_back(row);
}
}
Database optimizations:
- Vectorized execution (process columns in batches)
- Predicate reordering (most selective first)
- Compiled queries (eliminate interpretation overhead)
Vectorized databases like DuckDB, ClickHouse achieve order-of-magnitude improvements.
15. Compiler Optimizations for Branches
Compilers employ sophisticated techniques to improve branch behavior.
15.1 If-Conversion
Convert branches to conditional moves:
// Original
if (condition) {
x = a;
} else {
x = b;
}
// If-converted (compiler generates CMOV)
x = condition ? a : b;
Compilers apply if-conversion when:
- Both paths are simple
- Branch is likely unpredictable
- Architecture supports conditional moves
15.2 Branch Probability Propagation
Compilers track branch probabilities through the code:
if (error_check()) { // Rare: 0.01%
handle_error(); // Also rare
return;
}
// Normal path: 99.99%
do_work();
Probabilities inform:
- Code layout (hot path falls through)
- Inlining decisions (inline hot paths)
- Register allocation (optimize for hot path)
15.3 Hot/Cold Splitting
Move unlikely code out of hot paths:
// Before
void process() {
if (unlikely(error)) {
// 100 lines of error handling
}
// Hot path
}
// After (compiler splits)
void process() {
if (unlikely(error)) {
handle_error_cold(); // Outlined to separate function
}
// Hot path (better instruction cache)
}
Cold code outlining improves instruction cache utilization for hot paths.
15.4 Loop Unswitching
Hoist loop-invariant conditions:
// Before
for (int i = 0; i < n; i++) {
if (flag) { // Loop-invariant!
work_a(i);
} else {
work_b(i);
}
}
// After unswitching
if (flag) {
for (int i = 0; i < n; i++) {
work_a(i);
}
} else {
for (int i = 0; i < n; i++) {
work_b(i);
}
}
Eliminates n-1 branches, improving prediction and enabling further optimizations.
15.5 Speculative Compilation
JIT compilers can optimize based on runtime behavior:
// HotSpot JVM
if (obj instanceof Dog) { // 99% Dog
((Dog) obj).bark();
}
// JIT generates:
// if (obj.class="cc5659a" Dog.class) { // Fast path: direct call
// dog_bark(obj);
// } else {
// slow_path_instanceof(obj); // Deoptimize if assumption broken
// }
This “speculative optimization” bets on observed patterns, with fallback for uncommon cases.
16. Branch Prediction in Different Domains
16.1 Embedded Systems
Resource-constrained embedded systems have simpler predictors:
- Cortex-M series: Static or simple bimodal
- Smaller BTBs (32-128 entries)
- Lower misprediction penalties (shorter pipelines)
Embedded developers often:
- Avoid complex control flow
- Use lookup tables instead of branches
- Manually unroll critical loops
16.2 High-Frequency Trading
HFT systems are extremely latency-sensitive:
- Every nanosecond matters
- Branch mispredictions are critical path
- Custom hardware (FPGAs) avoids branches entirely
HFT optimizations:
// Branchless comparison
int cmp = (a > b) - (a < b); // Returns -1, 0, or 1
// Branchless min/max
int min = b + ((a - b) & ((a - b) >> 31));
// Pre-computed decision tables
action = decision_table[state][event];
16.3 Scientific Computing
Scientific code is often predictable (regular loops over arrays):
! Matrix multiplication - highly predictable
do i = 1, n
do j = 1, n
do k = 1, n
C(i,j) = C(i,j) + A(i,k) * B(k,j)
end do
end do
end do
But irregular data structures cause problems:
// Sparse matrix - unpredictable access patterns
for (int i = 0; i < nnz; i++) {
if (col[i] == target_col) { // Unpredictable!
sum += val[i];
}
}
Scientific libraries optimize sparse operations carefully.
16.4 Cryptographic Code
Cryptography requires constant-time execution to prevent timing attacks:
// WRONG: Timing depends on secret key bits
if (secret_key[i]) {
result = operation_a();
}
// RIGHT: Always execute both, select result
result_a = operation_a();
result_b = operation_b();
mask = -(secret_key[i] & 1); // All 1s or all 0s
result = (result_a & mask) | (result_b & ~mask);
Constant-time code deliberately avoids prediction-dependent timing.
17. Future Directions
17.1 Learned Predictors
Machine learning for prediction shows promise:
- Neural network-based BTB indexing
- Reinforcement learning for table management
- Transfer learning from similar workloads
Challenges:
- Inference latency (must be < 1 cycle)
- Training complexity
- Generalization to new workloads
17.2 Software-Hardware Co-design
Better compiler-hardware communication:
- Richer branch hints from compilers
- Hardware profiling feedback to compilers
- Adaptive optimization based on runtime behavior
17.3 Security-First Predictors
Post-Spectre designs prioritize security:
- Isolated prediction domains per security context
- Speculative execution firewalls
- Prediction state clearing on context switches
17.4 Heterogeneous Prediction
Different predictors for different branch types:
- Simple predictor for loop branches
- Neural predictor for data-dc14dc3 branches
- Table-based for indirect branches
Dynamic selection based on branch characteristics.
18. Summary
Branch prediction is a cornerstone of modern CPU performance:
- Deep pipelines require prediction to avoid stalls
- Dynamic predictors learn from runtime behavior
- Modern designs (TAGE, perceptron) achieve ~97% accuracy
- Speculation enables out-of-order execution but creates security risks
- Code patterns dramatically affect prediction accuracy
Key takeaways for developers:
- Predictable branches are nearly free (~0 cycles overhead)
- Unpredictable branches are expensive (10-25 cycles penalty)
- Sorting data can dramatically improve prediction
- Branchless code is only faster for unpredictable branches
- Profile your code to find branch hotspots
- Understand the architecture to write efficient code
The branch predictor is the CPU’s crystal ball, making educated guesses millions of times per second. Understanding how it works transforms how you think about the true cost of a simple if statement.
Every branch in your code is a bet. The CPU is gambling on the future, billions of times per second. Understanding these bets helps you write code that wins more often.
