Building a Monster: Minimal Perfect Hashing with Seed Chord and Bucket Hashing

1. Introduction: The Problem of Zero-Collision Lookup

You are staring at a problem. It’s not a bug—it’s a constraint. You have a static set of keys: 100,000 English words for a spellchecker, 50,000 IP addresses in a network filter, or perhaps 10,000 keywords for a compiler. You need to answer one question, over and over again, billions of times: “Is this key in the set? If so, where is its data?”

The naive solution is a binary search. It’s predictable, it works, but it costs log(N) comparisons per lookup. For 100,000 keys, that’s about 17 steps. In a high-performance system, 17 cache misses or string comparisons can feel like a lifetime. The elegant solution is a hash table. It offers O(1) average-case lookup. But “average-case” is the devil whispering in your ear. Collisions happen. Load factors degrade. Open addressing can lead to clusters of probes. Memory is wasted on empty buckets, multiplication factors, and rehashing overhead.

What if you could have a hash table that was guaranteed to have zero collisions? What if it could be perfectly dense, using exactly one slot per element, with no wasted memory? This is the promise of the Perfect Hash Function (PHF) . It is a function that maps a set of N keys to a set of N integers in the range [0, N-1], injectively. No collisions. Every key gets its own private integer index.

The problem? General-purpose PHFs are notoriously difficult to construct. For an arbitrary dynamic set, finding such a function is often computationally infeasible. However, you aren’t building for a dynamic set. You are building for a static set—a collection of keys known at compile-time. This changes everything. For static sets, we can trade construction-time complexity for lookup-time speed and memory efficiency. We can build a Monster.

Enter the Minimal Perfect Hash Function (MPHF) . It’s not just a perfect hash; it’s minimal: the output range is exactly [0, N-1]. No gaps. This means the associated table can be stored as a dense array, using exactly N slots. This is the holy grail for memory‑constrained environments: you can store a pointer or an integer per key, with zero overhead for collision resolution.

But building an MPHF is not trivial. Over the past decades, several algorithms have been proposed: the “hash‑and‑displace” approach, the RecSplit method, the CHD algorithm, and a family of methods based on random hypergraphs (e.g., BDZ). In this post, we will dive deep into two related but distinct techniques: Seed Chord and Bucket Hashing. These are often mentioned in the literature but rarely explained in a step‑by‑step manner. By the end of this article, you will understand how they work, how to implement them, and when to choose one over the other.

We will walk through the theory, provide worked examples, and present ready‑to‑use Python and C++ code snippets. We will also discuss the trade‑offs in terms of construction time, lookup speed, and memory footprint. Buckle up—we are about to build a Monster.

2. Foundations: What is a Hash Function, Really?

Before we can appreciate perfect hashing, we must revisit the basics. A hash function h maps a key k (typically a string or a block of bytes) to an integer bucket in some range [0, M‑1]. For a good general‑purpose hash function (e.g., CityHash, xxHash, or SipHash) the distribution of outputs is uniform and unpredictable. That uniformity is exactly what we rely on for hash tables.

Unfortunately, because the number of possible keys is vastly larger than M, collisions are inevitable. When two distinct keys hash to the same bucket, we must resolve the conflict. The usual strategies—separate chaining, open addressing with linear probing, or cuckoo hashing—all add overhead. Linear probing can cause clustering, and chaining adds pointers and separate memory allocations.

2.1 Perfect Hashing: The Ideal Case

A Perfect Hash Function for a set S of N keys satisfies:

• For any k1 != k2 in S, h(k1) != h(k2).
• The output range is [0, M‑1] where M ≥ N.

If M = N, the hash is minimal. That means we waste exactly zero slots.

The existence of a PHF for any static set is guaranteed (by the pigeonhole principle? Actually, the standard proof uses the fact that there are finite many hash functions and the probability that a random one is perfect is positive for sufficiently large M, but minimality adds a constraint). For N ≤ 1000, a brute‑force search over random hash parameters often works. For larger sets, we need more clever construction.

2.2 Construction vs. Evaluation Trade‑off

The main insight: for a static set, we can invest a lot of computation once to build a small data structure (the “description” of the MPHF) that then allows O(1) evaluation. The description typically occupies less than 4 bits per key (in the best known methods), but most practical implementations use around 2-6 bits per key. Lookup involves a few hash computations and possibly one or two table lookups.

The two methods we will examine—Seed Chord and Bucket Hashing—both follow a two‑level scheme:

1. First level: Partition the set of keys into buckets using a coarse hash.
2. Second level: Within each bucket, resolve collisions in a perfect way, often by finding a “seed” that makes a small hash function injective for the keys in that bucket.

The difference lies in how the seed is encoded and how the buckets are handled.

3. The Seed Chord Method

The Seed Chord method was first described by Fox, Chen, and Heath in the early 1990s (see “A faster method for constructing minimal perfect hash functions”). It is elegant: we treat each key’s hash value as a number, and we try to find a vector of offsets (seeds) such that the sum of the seed and the hash of the key, modulo the bucket size, gives a unique index.

3.1 Algorithm Overview

Given a set S of N keys:

1. Hash to buckets: Choose a primary hash function h0 that maps keys to integers in [0, B-1] where B is somewhat larger than N (e.g., B ≈ 1.3N). We call each integer a bucket index.
2. Create bucket lists: For each bucket b, collect all keys that hash to b. Let size[b] be the number of keys in bucket b.
3. Sort buckets: Process buckets in descending order of size (largest first). This is critical for success probability.
4. Assign seeds: For each bucket in order, we try to find a seed s (an integer in some range, say 0..P-1) such that the function:
   h(k, s) = (h1(k) ⊕ s) mod size[b] (or addition, or XOR)
   maps each key in that bucket to a unique integer in [0, size[b]-1]. The seed s is stored in an array seed[b].
5. Global mapping: The final index for a key is computed as:
   index = sum_{i < bucket(k)} size[i] + offset_in_bucket(k),
   where offset_in_bucket(k) = (h1(k) ⊕ seed[bucket(k)]) mod size[bucket(k)].

The construction succeeds if we can find a seed for every bucket. Because buckets are processed largest first, the smaller buckets have more freedom. Experiments show that with B ≈ 1.3N, success is almost guaranteed after a few random tries.

3.2 Why “Chord”?

The name “Seed Chord” comes from the idea of selecting a seed (a numerical chord) that harmonizes with the keys in the bucket to produce a perfect mapping. The term is not widely used outside older literature, but I find it evocative.

3.3 Detailed Example

Let’s build a minimal perfect hash for the set of 6 words: {apple, banana, cherry, date, elderberry, fig}. We’ll use small numbers for illustration.

Step 1: Choose parameters

• Let N = 6. Choose B = 8 (slightly larger than N).
• Primary hash h0: compute as (sum of ASCII values) mod B for simplicity.
• Secondary hash h1: compute as (product of ASCII values) mod some range.

Actually, let’s use concrete numbers:

• apple: ASCII sum = 97+112+112+108+101 = 530. h0 = 530 mod 8 = 2. h1 = (97112112108101) mod 1000 = … we’ll just invent small numbers to keep it manageable.

Better: Use a real random function. For clarity, assume the primary hash gives bucket indices as follows:

Step 2: Buckets Bucket 0: empty 1: empty 2: {apple (h1=5), cherry (h1=7)} → size 2 3: {elderberry (h1=6)} → size 1 4: empty 5: {banana (h1=2), fig (h1=4)} → size 2 6: empty 7: {date (h1=1)} → size 1

Step 3: Sort buckets by size descending Largest size = 2: buckets 2 and 5. Process them first.

Step 4: For bucket 2, size = 2. We need a seed s such that (h1 xor s) mod 2 maps both keys to distinct values 0 and 1.

• For apple: (5 xor s) mod 2 = (5 xor s) & 1.
• For cherry: (7 xor s) mod 2 = (7 xor s) & 1. We need the parity of (5 xor s) ≠ parity of (7 xor s). The parity of a number is the LSB. 5 xor s and 7 xor s will have same parity if (5 xor s) and (7 xor s) have same LSB. The LSB of (x xor s) = (LSB of x) xor (LSB of s). So requirement: (5&1) xor (s&1) ≠ (7&1) xor (s&1) → 1 xor s_bit ≠ 1 xor s_bit? Wait: 5&1=1, 7&1=1, so both parity bits are 1. Then (1 xor s_bit) and (1 xor s_bit) are always equal! So no seed will work with XOR? That’s a problem. Actually, XOR with same LSB will always give same parity if both h1 have same LSB.

We can use addition modulo size instead. Let’s try: (h1 + s) mod size. For bucket 2: size=2. Need s such that (5+s) mod 2 ≠ (7+s) mod 2. That is (5+s) and (7+s) have different parity. Since 5 and 7 have same parity, adding s won’t change difference. So fails too.

Hence we need a different secondary hash function. Perhaps we use a random permutation within the bucket: compute (h1 * a + b) mod M where a and b are small integers. In practice, the original Seed Chord method uses a function like (a*h1 + b) mod size, where a and b are stored as seeds. For this example, we might need to choose a different h0 so that no bucket contains keys with colliding h1 values. In real implementations, multiple random h1 functions are tried.

Let’s sweep this under the rug and pretend we have a second hash h2 that gives values 3 and 8 for apple and cherry, and (3 mod 2)=1, (8 mod 2)=0, so a seed of 0 works.

Step 5: For bucket 5, keys banana (h2=2) and fig (h2=4). 2 mod 2=0, 4 mod 2=0 → same parity again. So we need a different h2. Yes, failure is possible but rare.

For simplicity, assume we succeed with some seeds.

Step 6: Compute cumulative offset Buckets sorted by index (we need to know the global order). Let’s order buckets 0..7. Cumulative size before bucket i = sum of sizes of buckets < i. Bucket 0: size 0, cum=0 1:0, cum=0 2: size 2, cum=0 3: size 1, cum=2 4:0, cum=3 5: size 2, cum=3 6:0, cum=5 7: size 1, cum=5

So final index for apple: bucket=2, cum=0, offset_in_bucket = (h2(apple) ⊕ s2) mod 2. Suppose offset=1. Then index = 0+1=1. Cherry: offset=0 → index=0. Elderberry: bucket3, cum=2, offset=(h2 xor s3) mod1 → always 0, index=2. Banana: bucket5, cum=3, offset=(h2 xor s5) mod2. Suppose offset=0 → index=3. Fig: offset=1 → index=4. Date: bucket7, cum=5, offset=0 → index=5. We have indices 0..5, minimal.

3.4 Implementation Sketch in Python

import random

class SeedChordMPHF:
    def __init__(self, keys, B=None, tries=10):
        self.N = len(keys)
        if B is None:
            B = int(self.N * 1.3) + 1
        self.B = B
        # Try until success
        for _ in range(tries):
            self.h0_seed = random.randint(0, 2**31)
            self.h1_seed = random.randint(0, 2**31)
            buckets = [[] for _ in range(B)]
            for k in keys:
                b = self._h0(k)
                buckets[b].append((k, self._h1(k)))
            # Sort buckets by descending size
            bucket_indices = sorted(range(B), key=lambda i: -len(buckets[i]))
            self.seeds = [0]*B
            self.cum_sizes = [0]*B
            cum = 0
            for i in bucket_indices:
                self.cum_sizes[i] = cum
                cum += len(buckets[i])
                if len(buckets[i]) > 0:
                    # find seed
                    for s in range(256):  # try small seeds
                        used = set()
                        ok = True
                        for key, h1 in buckets[i]:
                            off = (h1 ^ s) % len(buckets[i])
                            if off in used:
                                ok = False
                                break
                            used.add(off)
                        if ok:
                            self.seeds[i] = s
                            break
                    else:
                        # failure - need to restart whole construction
                        break
            else:
                # all buckets succeeded
                self.constructed = True
                return
        raise Exception("Failed to construct MPHF")

    def _h0(self, key):
        # Simple hash using built-in hash
        return (hash(key) ^ self.h0_seed) % self.B

    def _h1(self, key):
        return (hash(key) ^ self.h1_seed) & 0xFFFF  # arbitrary range

    def lookup(self, key):
        b = self._h0(key)
        h1 = self._h1(key)
        off = (h1 ^ self.seeds[b]) % len(self.bucket_sizes)  # need sizes
        # Actually we need the size of bucket b. We stored cum_sizes but not size.
        # We can compute size by diff: if we have next cum_sizes...
        # For simplicity, store bucket_sizes list.
        return self.cum_sizes[b] + off

This is a simplified version. In practice, we store the bucket sizes in a separate array.

3.5 Performance Characteristics

• Construction time: O(N) average, but worst-case can be high if many restarts. With B ≈ 1.3N, the probability of needing more than one trial is small (around 10% for large N, but can be reduced by using larger B or more h1 bits).
• Lookup time: 2 hash computations + 1 array access + a small modulo/bitwise operation. Very fast.
• Memory: We need to store the seed array (one integer per bucket) and the cumulative sizes (one integer per bucket). That’s 2*B integers. With B ≈ 1.3N, memory is about 2.6N words. If we store seeds as 16-bit, that’s 2.6N * 2 bytes = 5.2N bytes, plus the cumulative sizes maybe 4 bytes each → total ~10N bytes. That’s about 10 bytes per key, which is decent but not competitive with modern methods like CHD or BDZ that achieve 2-3 bits per key.

However, the seeds can be compressed: many buckets have size 0 or 1, needing no seed. For size 1 buckets, any seed works, but we still store a dummy. We could avoid storing seeds for size 0 or 1 buckets, reducing memory. Also cumulative sizes can be stored as bit‑packed integers.

The main advantage of Seed Chord is simplicity and fast lookup for moderate sizes (up to 1 million keys). It was used in early compilers and databases.

4. Bucket Hashing: A More Modern Approach

Bucket Hashing, sometimes called “multipartite hashing” or “hash‑and‑displace”, is the basis of several state‑of‑the‑art MPHF algorithms such as CHD (Compress, Hash, Displace) and FCH (Fox, Chen, Heath). The core idea is similar to Seed Chord but with a crucial twist: we use a random hash function per bucket and encode that choice in a compact bit vector.

4.1 How Bucket Hashing Works

1. First level hashing: Just like Seed Chord, we use a primary hash h0 to assign each key to a bucket. The number of buckets B is chosen so that most buckets have very few keys (often 1 or 2). Typically B is a bit larger than N, e.g., B = 0.75N (for a load factor of 0.75? Actually for perfect hashing we want small buckets, so B ≈ N/2? Wait, let’s be precise.)

In CHD, they pick B such that the expected bucket size is about 2 (so B ≈ N/2). That means many buckets will have size 0, 1, 2, or occasionally 3. The construction is then similar to Seed Chord but with a different seed encoding.

2. Second level for each bucket: For each non‑empty bucket, we want to find a hash function (usually parametrized by a small integer seed) that maps the keys in that bucket to distinct positions in a global slot array. The positions for bucket i form a contiguous block of size equal to the bucket size. The challenge is to assign these blocks in a way that avoids collisions across buckets. In CHD, this is done by processing buckets in order of decreasing size and trying seeds until a perfect mapping is found within the global range (which is of size N). The seeds are stored in a compact data structure (a bit vector of length sum of bucket sizes).

3. Compact encoding: Instead of storing a full integer per bucket, we can store a descriptor that encodes the seed and the offset of the bucket’s block. This is where the “compress” step comes in. For each bucket of size s, the number of possible seeds that work is limited; we can often encode the selection in fewer than log2(N) bits, using, e.g., a variable‑length code or a lookup in a precomputed table.

4.2 The CHD Algorithm (Closest Relative)

The CHD algorithm (compress‑hash‑displace) by Belazzougui, Botelho, and Dietzfelbinger (2009) is a practical implementation of bucket hashing. Here is a rough outline:

1. Hash into small buckets using a primary hash function with a random seed. The number of buckets is chosen so that the largest bucket size is small (say ≤ 3 or 4) with high probability.
2. Sort buckets by size.
3. For each bucket, attempt to find a seed (a small integer) and a displacement value (an offset into the final table) such that the keys map to empty slots. The displacement is at most N - bucket size.
4. Store the seeds and displacements in a compressed form. For buckets of size 1, the displacement is arbitrary (just the next free slot), so no seed is needed. For size 2, we might store 2 bits indicating which of 4 possible hash functions works, etc.

The final data structure is often called a “minimal perfect hash function” description. Typical memory usage is 2-3 bits per key, and lookup is 1-2 hash evaluations plus a few bit operations.

4.3 Seed Chord vs. Bucket Hashing: A Comparison

For many use cases, especially in embedded systems or when memory is not tight, Seed Chord is perfectly fine. For internet‑scale static sets (e.g., URL deduplication with 1 billion entries), you need the tiny footprint of CHD.

5. Deep Dive: Constructing an MPHF with Bucket Hashing in Python

Let’s implement a simplified version of bucket hashing that is still practical. We will not implement the full compression (to keep code readable), but we will illustrate the core idea.

5.1 Step‑by‑Step Implementation

import random
import math

class BucketHashingMPHF:
    def __init__(self, keys, target_bits_per_key=3.0):
        self.N = len(keys)
        # Heuristic: choose number of buckets such that max bucket ~4
        # Expected max bucket size for N keys into B buckets is O(log B / log log B)
        # We'll use B = int(N / 2) to get average bucket size 2.
        B = int(self.N / 2) + 1
        self.B = B
        self.h0_seed = random.randint(0, 2**31)
        self.h2_seed = random.randint(0, 2**31)
        # Build buckets
        buckets = [[] for _ in range(B)]
        for k in keys:
            b = self._h0(k)
            buckets[b].append(k)
        # Sort buckets by descending size
        bucket_indices = sorted(range(B), key=lambda i: -len(buckets[i]))
        # Initialise global slots: we will assign final indices 0..N-1
        slots = [-1] * self.N  # -1 means free
        self.seeds = [0] * B
        self.offsets = [0] * B
        next_free = 0
        for b in bucket_indices:
            sz = len(buckets[b])
            if sz == 0:
                continue
            # Try seeds until we find a mapping that uses free slots
            found = False
            for s in range(256):  # try small seeds
                # compute offsets for this bucket using h2 with seed s
                positions = [self._h2(k, s) for k in buckets[b]]
                # We need to map these positions to actual free slots.
                # Here we assume positions are in [0, sz-1] and we assign them contiguous block starting at some offset.
                # But that would be like Seed Chord. In CHD, we want to assign each key to a globally unique slot.
                # The standard method: for each key, compute its "candidate" as (h2(k,s) mod sz) + offset_b? No.
                # Actually in CHD, the displacement is a global offset; each key maps to (h2(k,s) mod sz) + offset.
                # We need to choose an offset such that all resulting positions are free in the slots array.
                # Let's implement the "offset" approach: try offsets from 0 to N-sz.
                for offset in range(0, self.N - sz + 1):
                    ok = True
                    for k in buckets[b]:
                        pos = (self._h2(k, s, sz) ) + offset
                        if pos >= self.N or slots[pos] != -1:
                            ok = False
                            break
                    if ok:
                        # assign slots
                        for k in buckets[b]:
                            pos = (self._h2(k, s, sz)) + offset
                            slots[pos] = k
                        self.seeds[b] = s
                        self.offsets[b] = offset
                        found = True
                        break
                if found:
                    break
            if not found:
                raise Exception("Failed for bucket %d, size %d" % (b, sz))
        # Now build quick lookup array: for each key, store its index
        self.index_map = {k: i for i, k in enumerate(keys)}  # we already know final indices from slots
        # Actually we need the final index, not just position. We'll compute from slots.
        # Better: after construction we know each key's position = index.
        # Let's store mapping from key to final index in a dict for quick lookup.
        # But that defeats purpose; we want O(1) without dict. So we need to store offsets etc.
        # For simplicity, we'll just store the slots array and lookup via linear scan? No.
        # In practice, we don't store slots; we store seeds and offsets.
        # We'll create a method lookup(key) that computes bucket and then uses seed/offset.
        self.final_indices = {k: i for i, k in enumerate(keys) if slots[i]==k}
        # Actually the final index is the position in slots array.
        self.slots = slots  # but we don't need it for lookup, only for demo.

    def _h0(self, key):
        return (hash(key) ^ self.h0_seed) % self.B

    def _h2(self, key, seed, sz):
        # simple hash: (hash(key) ^ seed) % sz
        return (hash(key) ^ seed) % sz

    def lookup(self, key):
        b = self._h0(key)
        s = self.seeds[b]
        off = self.offsets[b]
        sz = len(self.buckets[b])  # we need bucket size, not stored currently
        # We need to pre‑compute bucket sizes. Let's store them.
        # Omitted for brevity.
        return (self._h2(key, s, sz) + off) % self.N

This code is incomplete and illustrative. Real implementations use bit‑packed arrays and avoid the inner offset loop by storing displacements in a compressed form.

5.2 Compression Techniques

The key to low memory is storing the seeds and offsets in a compact form. For each bucket, the number of possible seed‑offset pairs that work is small. The algorithm can be designed so that the offset is uniquely determined by the bucket index and the seed (e.g., by allocating slots in a “first‑fit” order). In CHD, after processing all buckets, the seeds are packed into a bit string using a Huffman‑like code: the more frequent seed values (like 0 for size‑1 buckets) use fewer bits.

The result is a data structure that can be represented in as little as 2.5 bits per key, which is close to the information‑theoretic lower bound of about 1.44 bits per key (for very large N). In practice, 2-3 bits per key is common.

6. Practical Examples and Applications

6.1 Spellchecker

Imagine a static dictionary of 100,000 English words. With Seed Chord, we might use 10 bytes per key → 1 MB. With CHD, 3 bits per key → 37.5 KB. The entire MPHF description fits in L2 cache. Lookup is: hash word, compute bucket, compute offset, and compare the key at that slot (if we store keys in a separate array). That’s a constant time, often under 50 ns.

6.2 Compiler Keyword Table

Compilers need to quickly map identifiers to tokens. A minimal perfect hash for 100 keywords can be built at compile time (using a script) and embedded as a lookup table. This is exactly how many C compilers’ lexer tables work.

6.3 Static Routing Tables

Network routers often have a fixed set of IP prefixes. An MPHF can be used to index into a forwarding table with guaranteed O(1) lookup, avoiding expensive longest‑prefix matching for certain cases.

7. Advanced Topics

7.1 Order‑Preserving MPHF

Sometimes we want the hash to preserve a given order (e.g., lexicographic order). This is more restrictive and requires more complex algorithms (e.g., using segmented order‑preserving hashing). Neither Seed Chord nor CHD are order‑preserving out of the box.

7.2 Parallel Construction

Building an MPHF for billions of keys can be parallelized by splitting the set into independent chunks (e.g., using a very coarse first‑level hash) and then combining via a simple dictionary. This is used in systems like Google’s Robots application.

7.3 Handling Large Keys

For keys that are very long (e.g., URLs > 1000 characters), we can hash them first with a fast general‑purpose hash to a 64‑bit fingerprint, then use the MPHF on the fingerprints. This introduces a small probability of collisions, but for static sets it’s often tolerable if we store the original keys for verification.

8. Conclusion: Choose Your Monster Wisely

Minimal perfect hash functions are a powerful tool for static sets. They allow you to trade construction time for ultra‑compact representation and constant‑time lookup. Seed Chord is easy to implement and works well for moderate sets. Bucket hashing (CHD) is more complex but delivers memory efficiency that scales to billiards of keys.

Both follow the same philosophy: hash to buckets, then resolve collisions with a small seed. The difference lies in how much memory you are willing to spend to store those seeds.

In today’s world of big data, the ability to store a perfect hash for every word in Wikipedia (5 billion words) using only 1.5 GB is a marvel. Next time you write a spellchecker or a database index, consider building a Monster.

Now go forth and eliminate collisions.
