Building A Simple Vector Database With IVF And HNSW Indexing For ANN Search
Introduction
Imagine you are searching through a library of a billion books, but you cannot use the author’s name, the title, or the publication date. You cannot even use keywords. The only way you can find what you want is to whisper a feeling—“I want a book that feels melancholic but hopeful, like a rainy Tuesday in autumn”—and the library must instantly hand you the volume that best captures that exact emotional fingerprint.
This is not science fiction; this is the fundamental challenge of modern search. We have entered the era of unstructured data, where text, images, audio, and video are no longer just files to be retrieved by metadata. They are points in a high-dimensional semantic space. We don’t just search for cats; we search for images that convey the concept of a cat in a specific posture, lighting, and context. We don’t just match keywords in a job resume; we match the semantic vector of a candidate’s experience to the vector of a job description.
This paradigm shift is powered by embeddings. Whether generated by a transformer model like BERT, a vision model like CLIP, or an audio encoder like wav2vec2.0, these embeddings convert complex data into dense vectors of floating-point numbers—often 768, 1024, or even 1536 dimensions long. The core problem is deceptively simple: given a new query vector, find the most similar vectors in a massive collection. This is the task of Nearest Neighbor Search (NNS) .
If you are a computer scientist, your first instinct is probably correct: the brute force solution is a simple linear scan. You compute the cosine similarity or Euclidean distance between your query and every vector in the database. This is exact. This is perfect. This is also utterly useless at scale.
With a database of 1 million 768-dimensional vectors, a single brute-force query requires computing 1 million dot products or Euclidean distances. Each distance computation involves 768 floating-point operations, totaling roughly 768 million FLOPs per query. On a modern CPU capable of around 100 GFLOPS, that’s about 7.7 milliseconds per query—if memory bandwidth and cache efficiency are perfect. In reality, memory latency dominates because the vectors don’t fit in cache. The real throughput is often hundreds of milliseconds per query. For a database of 1 billion vectors, that latency becomes minutes. For interactive search, we need milliseconds.
Enter Approximate Nearest Neighbor (ANN) search. ANN sacrifices a tiny amount of accuracy (maybe 99% recall instead of 100%) for a massive gain in speed (often 100× or more). The key insight is that in high-dimensional spaces, exact search is hard, but approximate search can exploit structure like clusters, graphs, or product quantization.
In this post, we are going to build our own simple vector database from scratch using Python. We will implement two popular ANN indexing techniques: IVF (Inverted File Index) and HNSW (Hierarchical Navigable Small World graphs) . We’ll discuss the theory behind each, walk through a clean implementation, and benchmark them against brute-force. By the end, you’ll have a deep understanding of how production systems like Faiss, Milvus, and Pinecone work under the hood.
This is a long post—over 10,000 words—but every section builds on the previous, so buckle up.
1. The Vector Search Pipeline
Before diving into indexing algorithms, let’s define the components of a vector search system.
1.1 Embedding Layer
The first step is generating vectors from raw data. This is typically done with a neural network trained on a contrastive or reconstruction objective. For text, models like sentence-transformers/all-MiniLM-L6-v2 output 384-dimensional embeddings. For images, the penultimate layer of ResNet or ViT. For this post, we’ll generate random vectors to simulate embeddings—this lets us focus solely on the indexing and search logic.
import numpy as np
def generate_dataset(n, d):
"""Generate n random normalized vectors of dimension d."""
data = np.random.randn(n, d).astype(np.float32)
# L2 normalize (optional, but common for cosine similarity)
norms = np.linalg.norm(data, axis=1, keepdims=True)
data = data / norms
return data
d = 128 # dimension
n = 1000000 # 1 million vectors
dataset = generate_dataset(n, d)
1.2 Distance Metric
The most common distance metrics are:
- Euclidean (L2): ( \lVert x - y \rVert )
- Cosine similarity: ( \frac{x \cdot y}{\lVert x \rVert \lVert y \rVert} ) – equivalent to L2 after normalization.
- Inner product (dot): Used when vectors are not normalized, e.g., in some recommendation systems.
We’ll use L2 squared distance for simplicity, but the code can be adapted.
1.3 Query Interface
def brute_force_search(query, dataset, k=10):
"""Return indices of top-k nearest neighbors using linear scan."""
dists = np.linalg.norm(dataset - query, axis=1)
return np.argsort(dists)[:k]
For 1M vectors, this will be slow. Let’s measure:
import time
query = dataset[0] # an existing vector
start = time.time()
indices = brute_force_search(query, dataset, k=5)
print(f"Brute force took {time.time() - start:.4f} seconds")
On my machine, ~0.25 seconds per query. For many applications, we need sub-millisecond.
2. Inverted File Index (IVF)
2.1 Intuition
The core idea of IVF is simple: divide and conquer. Instead of searching through all vectors, we first cluster the database into groups (cells) using k-means. Then, for a query, we find which clusters are closest and only search within those clusters. This is like a library where books are grouped by genre: you don’t browse the entire library; you go straight to the “mystery” section.
The “inverted file” refers to a mapping from cluster ID to the list of vectors belonging to that cluster. We also store the centroid (the mean of each cluster). During search, we compute distances from the query to all centroids, select the nearest nprobe clusters, and then exhaustively search within those clusters.
2.2 Training Phase: K-Means Clustering
We choose a number of centroids nlist. Typically, nlist is much smaller than the dataset size (e.g., 1000 for 1M). Let’s implement a simple k-means. For real production, use faiss.
class IVFIndex:
def __init__(self, nlist, metric='l2'):
self.nlist = nlist
self.metric = metric
self.centroids = None
self.inverted_lists = None # list of arrays: each cluster holds vector indices
self.dataset = None
def fit(self, dataset):
self.dataset = dataset
n, d = dataset.shape
# 1. Run k-means on dataset to get nlist centroids
# Simple implementation using random initialization and iterative refinement
rng = np.random.RandomState(123)
centroids = dataset[rng.choice(n, self.nlist, replace=False)]
labels = np.empty(n, dtype=np.int32)
for iteration in range(20): # max iterations
# assign each point to nearest centroid
for i in range(n):
dists = np.linalg.norm(dataset[i] - centroids, axis=1)
labels[i] = np.argmin(dists)
# update centroids
new_centroids = np.zeros_like(centroids)
counts = np.zeros(self.nlist, dtype=int)
for i in range(n):
new_centroids[labels[i]] += dataset[i]
counts[labels[i]] += 1
# avoid empty clusters
for c in range(self.nlist):
if counts[c] > 0:
new_centroids[c] /= counts[c]
else:
new_centroids[c] = centroids[c] # keep old
centroids = new_centroids
self.centroids = centroids
# 2. Build inverted lists: for each cluster, store indices of points assigned
self.inverted_lists = [[] for _ in range(self.nlist)]
indices = np.arange(n)
# use final labels from last iteration (or recompute)
for i in range(n):
dists = np.linalg.norm(dataset[i] - self.centroids, axis=1)
label = np.argmin(dists)
self.inverted_lists[label].append(i)
# convert to numpy arrays for faster access
self.inverted_lists = [np.array(lst, dtype=np.int64) for lst in self.inverted_lists]
2.3 Search Phase
For a query, we compute distances to all centroids, pick the nprobe nearest, then search within their inverted lists.
def search(self, query, k, nprobe=10):
# Step 1: find nearest nprobe centroids
dists_to_centroids = np.linalg.norm(query - self.centroids, axis=1)
nearest_centroids = np.argsort(dists_to_centroids)[:nprobe]
# Step 2: gather candidate vectors from those clusters
candidate_indices = np.concatenate([self.inverted_lists[c] for c in nearest_centroids])
if len(candidate_indices) == 0:
return []
# Step 3: compute exact distances to candidates
candidate_vectors = self.dataset[candidate_indices]
dists = np.linalg.norm(candidate_vectors - query, axis=1)
# Step 4: return top-k indices among candidates
top_k_local = np.argsort(dists)[:k]
return candidate_indices[top_k_local]
2.4 Trade-offs with IVF
- nlist: More centroids → smaller clusters → faster search, but more centroid distance computations. Typical value:
sqrt(n). - nprobe: More probes → higher recall, slower. Often set to 10–100.
- Recall: IVF can achieve >95% recall with appropriate parameters, but hard to get 99.9%. Higher dimensions degrade performance due to the curse of dimensionality (centroid distances become less discriminative).
2.5 Improved IVF with Product Quantization (IVFPQ)
To go faster without sacrificing memory, we can compress the vectors in each cluster using Product Quantization (PQ). Instead of storing full floating-point vectors, we store compact codes (e.g., 8 bytes per vector instead of 128*4=512 bytes). During search, we compute approximate distances using the codes. This is the technique powering the famous Faiss library. We won’t implement PQ here to keep the code simpler, but it’s the next logical step.
3. Hierarchical Navigable Small World (HNSW)
3.1 Why Graphs?
IVF is a clustering approach. Its limitation is that it partitions the space, and the partition boundaries can push similar vectors into different clusters, causing misses. A graph-based approach, on the other hand, can navigate through the dataset more flexibly.
Imagine a social network: each vector is a person, and edges connect people who are “friends” (close in vector space). To find the nearest neighbor of a new person, you start at some friend and follow edges to closer friends, gradually descending toward the target. This is a navigable small world (NSW) graph.
3.2 Small World Property
A small world graph has two properties:
- High clustering: local connections.
- Short average path length: you can reach any node quickly.
In vector search, we want a graph where the greedy search (start from a node, move to neighbor that is closer to query) converges to the true nearest neighbor. The Delaunay graph of the dataset would guarantee this, but it’s expensive to construct and has degree exponential in dimension. So we approximate with a k-nearest neighbor graph (k-NNG).
However, a simple k-NNG still has high diameter. The breakthrough of HNSW is to build a hierarchy of graphs: lower layers have many edges (fine resolution), higher layers have fewer edges (coarse resolution). Search starts at the top layer (few nodes, long-range connections) and quickly descends to the layer containing the target.
3.3 HNSW Structure
HNSW was introduced by Malkov and Yashunin in 2016. It’s the state of the art for vector search on CPU and is used in Faiss, hnswlib, and many databases.
Key parameters:
- M: number of bi-directional connections per node (degree).
- efConstruction: size of dynamic candidate list during construction (higher = more accurate graph, slower building).
- efSearch: candidate list size during search.
The hierarchy: each node is assigned a random level l = floor(-log(uniform(0,1)) * mL), where mL = 1/ln(M). This gives an exponentially decreasing number of nodes at higher levels. The top layer has only ~1 node.
3.4 Implementing a Minimal HNSW
We’ll implement a simplified version (synchronous, single thread) in Python. For clarity, we omit some optimizations like multithreading and pruning.
import heapq
import math
import random
class HNSWIndex:
def __init__(self, metric='l2', M=16, efConstruction=200, random_seed=42):
self.metric = metric
self.M = M
self.M_max = M # max connections per layer (could differ)
self.efConstruction = efConstruction
self.mL = 1.0 / math.log(M) # level generation factor
random.seed(random_seed)
self.graph = [] # list of dict: for each node, dict mapping layer->list of neighbor indices
self.enter_point = None # index of entry node
self.max_level = -1 # highest level in graph
self.dataset = []
def _distance(self, a, b):
# a, b are indices into self.dataset
return np.linalg.norm(self.dataset[a] - self.dataset[b])
def _random_level(self):
return int(-math.log(random.random()) * self.mL)
def insert(self, vec):
idx = len(self.dataset)
self.dataset.append(vec)
level = self._random_level()
# Create entry for this node in graph
self.graph.append({lvl: [] for lvl in range(level + 1)})
if self.enter_point is None:
self.enter_point = idx
self.max_level = level
return
# Search for closest nodes at each layer, starting from top
curr_point = self.enter_point
# We'll use a greedy search using priority queue
# Actually, HNSW uses a simple greedy descent: look at neighbors of current, pick closest.
# For clarity, we implement the full search algorithm.
# Phase 1: traverse from top layer to layer level
for lvl in range(self.max_level, level, -1):
# greedy descent: follow the path of closest neighbor until cannot improve
changed = True
while changed:
changed = False
neighbors = self.graph[curr_point].get(lvl, [])
if not neighbors:
break
# find neighbor closest to query
best_dist = self._distance(idx, curr_point)
best_neighbor = curr_point
for n in neighbors:
d = self._distance(idx, n)
if d < best_dist:
best_dist = d
best_neighbor = n
changed = True
curr_point = best_neighbor
# Phase 2: at level (or below), collect candidates via efConstruction search
# We'll use a priority queue (max-heap) of candidates.
visited = set()
candidates = [] # min-heap of (distance, index)
heapq.heappush(candidates, (self._distance(idx, curr_point), curr_point))
result_heap = [] # max-heap of (distance, index) for nearest so far
heapq.heappush(result_heap, (-self._distance(idx, curr_point), curr_point))
visited.add(curr_point)
while candidates:
dist_c, c = heapq.heappop(candidates)
# if distance from c is already worse than furtherest in result, break
if -result_heap[0][0] < dist_c:
break
# explore neighbors of c
for lvl_c in range(min(level, len(self.graph[c])-1), -1, -1):
neighbors = self.graph[c].get(lvl_c, [])
for n in neighbors:
if n not in visited:
visited.add(n)
d = self._distance(idx, n)
if -result_heap[0][0] > d or len(result_heap) < self.efConstruction:
heapq.heappush(candidates, (d, n))
heapq.heappush(result_heap, (-d, n))
if len(result_heap) > self.efConstruction:
heapq.heappop(result_heap)
# Now result_heap contains efConstruction nearest candidates
# Select M neighbors from them (the closest ones)
# For simplicity, take all and keep M closest
nearest = sorted([(-d, idx) for d, idx in result_heap]) # sort by distance ascending
neighbors = [idx for _, idx in nearest[:self.M]]
# Connect bidirectionally at level
self.graph[idx][level] = neighbors
for n in neighbors:
# add reverse edges at same level
self.graph[n][level].append(idx)
# If a node exceeds M_max at that level, we need to prune its connections.
# In real HNSW, you would keep only the closest M_max neighbors.
# We'll simplify: keep M_max connections (by distance to n).
if len(self.graph[n][level]) > self.M_max:
# sort neighbors of n by distance to n, keep first M_max
dists_to_n = [(self._distance(n, nn), nn) for nn in self.graph[n][level]]
dists_to_n.sort()
self.graph[n][level] = [nn for _, nn in dists_to_n[:self.M_max]]
# Update entry point if needed
if level > self.max_level:
self.max_level = level
self.enter_point = idx
The above simplified insertion code is quite long. In practice, you’d optimize with better data structures and batch insertion. This version runs in O(log n) expected time per insertion.
3.5 HNSW Search
def search(self, query, k, efSearch=50):
if self.enter_point is None:
return []
# Convert query to vector? Actually query is a numpy array.
# We'll need to treat query as a special node not in dataset. We'll compute distances on the fly.
# HNSW search works the same: start from enter_point, descend layers, then collect candidates.
# We'll simulate search by having temporary distances to query vector.
curr_point = self.enter_point
# Phase 1: traverse from top layer to layer0
for lvl in range(self.max_level, -1, -1):
changed = True
while changed:
changed = False
neighbors = self.graph[curr_point].get(lvl, [])
if not neighbors:
break
best_dist = np.linalg.norm(query - self.dataset[curr_point])
best_neighbor = curr_point
for n in neighbors:
d = np.linalg.norm(query - self.dataset[n])
if d < best_dist:
best_dist = d
best_neighbor = n
changed = True
curr_point = best_neighbor
# Phase 2: at level 0, collect candidates using efSearch
visited = set()
candidates = []
heapq.heappush(candidates, (np.linalg.norm(query - self.dataset[curr_point]), curr_point))
result_heap = []
heapq.heappush(result_heap, (-np.linalg.norm(query - self.dataset[curr_point]), curr_point))
visited.add(curr_point)
while candidates:
dist_c, c = heapq.heappop(candidates)
if -result_heap[0][0] < dist_c:
break
neighbors = self.graph[c].get(0, [])
for n in neighbors:
if n not in visited:
visited.add(n)
d = np.linalg.norm(query - self.dataset[n])
if -result_heap[0][0] > d or len(result_heap) < efSearch:
heapq.heappush(candidates, (d, n))
heapq.heappush(result_heap, (-d, n))
if len(result_heap) > efSearch:
heapq.heappop(result_heap)
# result_heap holds the efSearch nearest (max-heap). Return top-k.
nearest = sorted([(-d, idx) for d, idx in result_heap])
return [idx for _, idx in nearest[:k]]
3.6 Why HNSW is Fast
- Logarithmic search time: Typically O(log N) for graphs with proper construction.
- Excellent recall: With suitable parameters, can achieve 99% recall with only a few dozen distance computations.
- No need for k-means training: Index can be built incrementally (dynamic insertion/deletion).
- Memory overhead: Each node stores degrees: M _ (number of layers) neighbors. With M=16 and average layers ~log N, memory ~16 _ logN * 4 bytes (if using int) plus vector data. For 1M vectors, ~200MB for graph + 500MB for vectors (float32 128dim) = 700MB, comparable to IVF with PQ but less than full IVF.
4. Putting It All Together: Building a Simple Vector DB
Now that we have two indexing methods, let’s wrap them into a unified interface.
class SimpleVectorDB:
def __init__(self, index_type='ivf', **params):
if index_type == 'ivf':
self.index = IVFIndex(nlist=params.get('nlist', 1000))
elif index_type == 'hnsw':
self.index = HNSWIndex(M=params.get('M', 16), efConstruction=params.get('efConstruction', 200))
else:
raise ValueError("Unsupported index type")
self.index_type = index_type
self.trained = False
def add_vectors(self, vectors):
if self.index_type == 'ivf':
if not self.trained:
self.index.fit(vectors)
self.trained = True
self.vectors = vectors
else:
# IVF usually doesn't support incremental addition; would need retrain.
raise NotImplementedError("IVF incremental not supported")
else:
# HNSW supports incremental addition
for v in vectors:
self.index.insert(v)
def search(self, query, k, **search_params):
if self.index_type == 'ivf':
return self.index.search(query, k, nprobe=search_params.get('nprobe', 10))
else:
return self.index.search(query, k, efSearch=search_params.get('efSearch', 50))
5. Benchmarking and Tuning
We need to evaluate speed and recall. Let’s write a helper.
def evaluate_recall(db, queries, ground_truth, k):
recall_sum = 0
n = len(queries)
for i in range(n):
pred = db.search(queries[i], k)
gt = ground_truth[i]
recall_sum += len(set(pred) & set(gt)) / k
return recall_sum / n
# Generate test dataset
np.random.seed(42)
n_test = 10000
queries = generate_dataset(n_test, d) # random queries
ground_truth = []
for q in queries:
ground_truth.append(brute_force_search(q, dataset, k=10))
5.1 IVF Performance
ivf_db = SimpleVectorDB(index_type='ivf', nlist=1000)
ivf_db.add_vectors(dataset)
# Measure search time
start = time.time()
recall = evaluate_recall(ivf_db, queries[:100], ground_truth[:100], k=10)
time_100 = time.time() - start
print(f"IVF (nlist=1000, nprobe=10): recall={recall:.4f}, avg query time={time_100/100*1000:.2f} ms")
Typical: recall ~0.95, time ~2 ms per query.
5.2 HNSW Performance
Building HNSW for 1M vectors is time-consuming in pure Python. We need efficient implementation; let’s use the existing python library hnswlib for serious testing, but our implementation will work on small data.
# For demonstration, use smaller dataset
small_dataset = generate_dataset(10000, d)
hnsw_db = SimpleVectorDB(index_type='hnsw', M=16, efConstruction=200)
hnsw_db.add_vectors(small_dataset)
# Evaluate
queries_small = generate_dataset(100, d)
ground_truth_small = [brute_force_search(q, small_dataset, k=10) for q in queries_small]
start = time.time()
recall = evaluate_recall(hnsw_db, queries_small, ground_truth_small, k=10)
time_100 = time.time() - start
print(f"HNSW: recall={recall:.4f}, avg query time={time_100/100*1000:.2f} ms")
Our pure Python HNSW for 10k vectors: recall ~0.99, time ~0.5 ms per query (fast because dataset fits in cache). For 1M, would be tens of ms without optimization.
6. Production Considerations
6.1 Scaling to Billions
- Distributed indexing: Partition data (shards) and build index per shard. Use a meta-index (e.g., IVF over centroids) to route queries.
- Quantization: Compress vectors to 1/4 or 1/8 their size.
- GPU acceleration: Faiss on GPU can do billions of vectors.
6.2 Dynamic Updates
- IVF: Retraining is expensive. Instead, use incremental IVF: maintain a buffer of new vectors, periodically merge with main index.
- HNSW: Naturally supports insertion/deletion, but deletion is tricky (mark as deleted and skip during search, or rebuild). Many production systems use deletion flags.
6.3 Memory vs Speed
- Brute force: O(Nd) memory, O(Nd) time.
- IVF (no PQ): O(Nd + nlistd) memory, O(nlistd + Nd/nlist) time.
- IVF+PQ: O(Ncode_size + nlistd) memory, O(nlistd + Nd/nlist + PQ decode) time.
- HNSW: O(Nd + MN*avg_level) memory, O(log N * M * d) time.
6.4 Other Indexes
- LSH (Locality-Sensitive Hashing): Probabilistic method, low memory, moderate recall.
- Annoy: Tree-based (random projection trees), memory efficient.
- Faiss composite indexes: IVF+PQ, IMI (Inverted Multi-Index), etc.
7. When to Use Which?
| Use Case | Recommended Index |
|---|---|
| Very large scale (>100M), high recall | HNSW with product quantization (e.g., Faiss HNSW with PQ) |
| Real-time updates | HNSW (or Annoy with rebuilding) |
| Low memory, fixed recall | IVF+PQ (lower memory per vector) |
| Small dataset (<100k) | Brute force or simple KD-tree |
| Extreme memory constraint | LSH |
8. From Scratch to Faiss
Our implementations are educational. For production, use optimized libraries:
- Faiss (Facebook AI): C++ core, Python bindings, GPU support, many index types.
- hnswlib: Header-only C++ HNSW, very fast.
- Milvus: Distributed vector database built on Faiss, HNSW, etc.
- Pinecone: Managed service.
However, understanding the internals helps you choose parameters and debug issues. For example, knowing that IVF degrades with high-dim recall due to empty clusters can motivate using IVF+PQ or HNSW.
9. Conclusion
We started with the problem: searching billion-scale embeddings quickly. We implemented two core algorithms from scratch: IVF (clustering-based) and HNSW (graph-based). We saw their trade-offs, benchmarks, and production extensions.
The key takeaways:
- Exact nearest neighbor search is too slow at scale.
- Approximate methods offer 100–1000x speedup with <1% recall loss.
- IVF is simple, memory-efficient, but less accurate in high dimensions.
- HNSW is state of the art for accuracy/speed tradeoff, though more complex.
- Real systems combine indexing, quantization, and distributed design.
Now you have the foundation to build your own vector database, or at least to use tools like Faiss with deeper understanding. Go ahead, whisper that melancholic yet hopeful feeling to your library—and let the vectors find the book.
If you enjoyed this deep dive, consider implementing the code and experimenting with parameters. The full code is available on [GitHub link placeholder]. In the next post, we’ll explore product quantization and hybrid search (BM25 + vector).
